Felicity 5.12 kWh LUX-X-48100LMG01

Capacity: 5.1 kWh
Availability: On order
Minimum order: 1 pcs

Downloads

PDF Datasheet — lux-x-48100lg01 1.1 MB

Price on request

We will check availability and get back to you with this information.

Nothing to pay now.

Description

Battery module Felicity LUX-X-48100LMG01 with 5.12 kWh capacity, LiFePO4 (LFP), low voltage (LV), voltage 51.2 V. Operating voltage 44.8–57.6 V, depth of discharge 95%, communication CAN,RS485, IP rating IP21. Application: residential. Dimensions 333 × 450 × 600 mm (H × W × D), weight 46 kg.

Manufacturer information

A single battery module. LiFePO4: Higher safe performance and longer cycle life Multiple Protection: Built-in smart BMS, Breaker and Fuse Flexible Installation: Movable type Floor-Mounted Wide Compatibility: Compatible with leading inverter brands High Scalability Modular design for easy installation and increased capacity Aerosol Fire Extinguishing System

Technical data

Product details

Series	LUX-X Battery Pack
System type (HV / LV)	Low voltage (LV)
Min. voltage	44.8 V
Max. voltage	57.6 V
Depth of discharge (DoD)	95 %
IP rating	IP21
Max. charge / discharge temperature	55/55 °C
Min. charge / discharge temperature	0/-20 °C
Communication protocol	CAN,RS485
