Victron BlueSolar Charge Controller MPPT 150/60 MC4

Prieinamumas: Sandėlyje
: Pasiūlymų skaičius: 4
Minimalus užsakymas: 1 vnt.
Incoterms: EXW

Atsisiuntimui

PDF Techninis aprašas — victron-bluesolar-charge-controller-mppt-15060-mc4 0,2 MB

Grynoji kaina pagal kiekį

nuo 243,96 €

Kiekio kainų ribos matomos registruotoms įmonėms.

Dabar nieko nemokate. Transporto kainą apskaičiuosime pateikus užsakymą; ją turėsite patvirtinti.

Aprašymas

Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers. Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP. Outstanding conversion efficiency No cooling fan. Maximum efficiency exceeds 98%. Flexible charge algorithm Fully programmable charge algorithm (see the software page on our website), and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details). Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor Compensates absorption and float charge voltage for temperature. Real-time data display options - Color Control GX or other GX devices: see the Venus documents on our website. - A smartphone or other Bluetooth-enabled device: VE.Direct Bluetooth Smart dongle needed.
