Victron LFP-Smart 12.8/330

Dostępność: Na zamówienie
Minimalne zamówienie: 1 szt.

Do pobrania

PDF Karta katalogowa — victron-lfp-smart-128330 0,3 MB

Cena na zapytanie

Sprawdzimy dostępność i wrócimy do Ciebie z tą informacją.

Teraz nic nie płacisz.

Opis

Bateria Victron LFP-Smart 12.8/330 o pojemności 330 Ah, LiFePO4 (LFP), napięcie 12,8 V. Wymiary 265 × 359 × 206 mm (wys. × szer. × gł.), waga 27 kg.

Informacje producenta

Victron Energy Lithium Battery Smart batteries are Lithium Iron Phosphate (LiFePO4) batteries and are available in 12.8 V or 25.6 V in various capacities. They can be connected in series, parallel and series/parallel so that a battery bank can be built for system voltages of 12 V, 24 V or 48 V. The maximum number of batteries in one system is 20, which results in a maximum energy storage of 84 kWh in a 12 V system and up to 102 kWh in a 24 V1) and 48 V1) system. A single LFP cell has a nominal voltage of 3.2V. A 12.8 V battery consists of 4 cells connected in series and a 25.6 V battery consists of 8 cells connected in series. Why lithium-iron-phosphate? Rugged A lead-acid battery will fail prematurely due to sulfation: • If it operates in deficit mode during long periods of time (i.e. if the battery is rarely, or never at all, fully charged). • If it is left partially charged or worse, fully discharged (yacht or mobile home during wintertime). A LFP battery: • Does not need to be fully charged. Service life even slightly improves in case of partial charge instead of a full charge. This is a major advantage of LFP compared to lead-acid. • Other advantages are the wide operating temperature range, excellent cycling performance, low internal resistance and high efficiency (see below). LFP is therefore the chemistry of choice for demanding applications. Efficient • In several applications (especially off-grid solar and/or wind), energy efficiency can be of crucial importance. • The round-trip energy efficiency (discharge from 100 % to 0 % and back to 100 % charged) of the average lead-acid battery is 80 %. • The round-trip energy efficiency of a LFP battery is 92 %. • The charge process of lead-acid batteries becomes particularly inefficient when the 80 % state of charge has been reached, resulting in efficiencies of 50 % or even less in solar systems where several days of reserve energy is required (battery operating in 70 % to 100 % charged state). • In contrast, a LFP battery will still achieve 90 % efficiency under shallow discharge conditions. Size and weight • Saves up to 70 % in space • Saves up to 70 % in weight Expensive? • LFP batteries are expensive when compared to lead-acid. But in demanding applications, the high initial cost will be more than compensated by longer service life, superior reliability and excellent efficiency. Bluetooth • With Bluetooth cell voltages, temperature and alarm status can be monitored. • Instant readout: The VictronConnect App can display the most important data on the Device list page without the need to connect to the product. • Very useful to localize a (potential) problem, such as cell imbalance. 1) To reduce required balancing time, we recommend to use a little different batteries in series as possible for the application. 24 V systems are best built using 24 V batteries. And 48 V systems are best built using two 24 V batteries in series. While the alternative, four 12 V batteries in series, will work, it will require more periodic balancing time.
